NJ2DG Central Jersey Digital Group

The NJ2DG Repeater System has G2 Gateway Access. All users accessing onto the new G2 gateway system nationally will need to register ONLY ONCE. If you choose, you can complete your initial G2 registration through the following link: https://rpt.nj2dg.org/Dstar.org

Once receiving an email confirmation confirming your registration then you must sign back in through the above link and you must complete the following steps after clicking the Personal Information tab

Each user must set the first line (# 1 of 8) to be able to use the Gateway.

1) Check the box next to number 1 to enable editing for the line

2) Put a SPACE in the box under "Initial"

3) Do NOT check the RPT box

4) Type your call sign in the pcname box in lower case

5) Click the Update button

You have now successfully completed the G2 gateway registration process. Questions(?)                                          -> please contact: Randy WA2RMZ at wa2rmz@nj2dg.org or Scott KB2EAR at kb2ear@nj2dg.org

Some systems listed as G2 gateways on https://rpt.nj2dg.org/Dstar.org webpage under GW Information tab may not be fully connected to a repeater system.

Programming by use the of the D-Star Calculator

http://www.dstarinfo.com/Calculator/DSTAR%20Web%20Calculator.aspx?Source=NJ2DG

D-Star Dashboard for Reflector 20

NJ2DG B and C are connected, see who else is connected. http://ref020.dstargaterway.org

KI4SWY Callsign Query for Gateway Registered Callsigns  This is small website interface that anybody can go to, and Query a callsign, and it will tell you which repeaters are they are registered on, and if they have any terminals registered: http://query.ki4swy.org

Gateway Programming

Programming Examples

Zone Call Example -> NJ2DG 440 Repeater to K5TIT 440 Repeater through the Gateway

URCALL =/K5TIT B This URCALL entry indicates that you are calling to K5TIT 440 Repeater, please

note the leading character is the / followed by the repeater call with the module B in the 8th character position.

RPT1  = NJ2DG B The B (440 Repeater) must be in the 8th character position

RPT2  = NJ2DG G The G (Gateway) must be in the 8th character position

MYCALL = your call sign

Gateway Call to a Individual -> Last Heard on the Gateway

URCALL = K7FAY Finding where K7FAY was last heard and trust server will automatically route your

gateway call to the last module that K7FAY was heard on.

RPT1 = NJ2DG B The B (440 Repeater) must be in the 8th character position

RPT2 = NJ2DG G The G (Gateway) must be in the 8th character position

MYCALL = your call sign

Gateway Call to Linked Repeaters with D-Plus (441.650 is currently linked to other repeaters)

URCALL = CQCQCQ

RPT1 = NJ2DG B The B (440 Repeater) must be in the 8th character position

RPT2 = NJ2DG G The G (Gateway) must be in the 8th character position

MYCALL = your call sign

Hot Spot / Node Simplex or Repeater

URCALL = CQCQCQ

RPT1 = None

RPT2 = None

MYCALL = your call sign
